Non-Destructive Particle Beam Diagnostics

NPCT

Bergoz NPCT

Non-destructive DC beam current measurement

  • Full Scale Range: ±20mA, ±200mA, ±2A, or ±20A
  • Resolution: 0.5 µArms /vHz
  • Bandwidth: DC to 10 kHz
  • Linearity error: 0.1%
Out of Stock

Bergoz FCT

Fast non-destructive pulsed or CW beams observation

  • Sensitivity: from 0.25 to 10 V/A
  • Bandwidth: up to 1.5 GHz
  • Rise time: 200 ps
Out of Stock

Bergoz IPCT DC/AC Current Transducer

DC/AC non-destructive current measurement for Industry

  • Full Scale Range: ±1 mA to ±20 A
  • Resolution: 1 µArms /vHz
  • Bandwidth: DC to 3.8 kHz (-3dB)
  • Aperture: 82 mm (3.23”)
Out of Stock
ACCT

Bergoz ACCT

Precise waveform measurement of long pulses

  • Full Scale Range: ±1 mA to ±2 A
  • Range: Single or 3-Selectable
  • Wideband noise: 1.5 µArms resolution
  • Droop: 2% / ms
  • Bandwidth:  From 3 Hz to 1 MHz (-3dB)
Out of Stock
CWCT_BCM-CW

Bergoz CWCT & BCM-CW-E

Precise average current measurement of CW beam and macropulses

  • Full Scale Range: ±2 mA to ±400 mA
  • Resolution: 1µA rms
  • Response Time: 1 µs
  • Operating Frequency: 15 MHz to 500 MHz











Out of Stock
ICT

Bergoz ICT & BCM-IHR, Turbo-ICT & BCM-RF-E

ICT & BCM-IHR  – No loss in bunch charge integration

  • Full Scale Range: from 800 pC to 400 nC
  • Noise on single bunch: 0.55 pC rms



Turbo-ICT & BCM-RF-E – Optimized for ultra short bunch and very low charge

  • Charge range: up to 300pC
  • Bench Length: 100 ps
  • Noise: 10 fC or 1% of charge
  • Bunch Repetition: 2 MHz
Out of Stock
MX-BPM

Bergoz MX-BPM & Log Ratio BPM

MX-BPM – Non-interceptive e-/p+ beam position module

  • Resolution X & Y    1 µm
  • Dynamic range      > 75 dB
  • Operating frequency  60 MHz to 800 MHz+



Log Ratio BPM – Single-pass bunches position modules

  • Available Models: LR, S, BB
  • Operating Frequency: from 200 kHz to 3 GHz
  • Resolution: 70.. 150 µm
  • Dynamic Range: > 50 dB
  • BB-BPM Frequency range: 200 kHz to 25 MHz
Out of Stock
S-BPM

Bergoz S-BPM

Fast analog processing of beam pickups signals.

  • Non-interceptive beam position measurement.
  • Beam charge range > 1000



















Out of Stock

Bergoz BLM

Low-Cost predicted beam low counting

  • Single particle detection efficiency: > 30%
  • Spurious count rate: < 0.1 Hz
  • Maximum count rate: > 10 MHz
Out of Stock

Bergoz CR-BCM

Current Measurement with sub-nanoamperes resolution of CW beams and macropulses

  • Beam repetition frequency from 30 MHz to 175 MHz
  • Response time  < 1 µs
  • 100 mm axial length
  • 300 mm external diameter
Out of Stock
